Siemens MICROMASTER 440 - Setpoint Channel; CI: Main Setpoint; CI: Main Setpoint Scaling; BI: Disable Additional Setpoint

Issue 01/06 Parameter Description
MICROMASTER 440 Parameter List
6SE6400-5BB00-0BP0
125
3.20 Setpoint channel
P1070[3] CI: Main setpoint Min: 0:0
CStat: CT Datatype: U32 Unit: - Def: 755:0
P-Group: SETPOINT Active: first confirm QuickComm.: No Max: 4000:0
Defines source of main setpoint.
Index:
P1070[0] : 1st. Command data set (CDS)
P1070[1] : 2nd. Command data set (CDS)
P1070[2] : 3rd. Command data set (CDS)
Common Settings:
755 = Analog input 1 setpoint
1024 = Fixed frequency setpoint
1050 = Motor potentiometer (MOP) setpoint
P1071[3] CI: Main setpoint scaling Min: 0:0
CStat: CT Datatype: U32 Unit: - Def: 1:0
P-Group: SETPOINT Active: first confirm QuickComm.: No Max: 4000:0
Defines source of the main setpoint scaling.
Index:
P1071[0] : 1st. Command data set (CDS)
P1071[1] : 2nd. Command data set (CDS)
P1071[2] : 3rd. Command data set (CDS)
Common Settings:
755 = Analog input 1 setpoint
1024 = Fixed frequency setpoint
1050 = Motor potentiometer (MOP) setpoint
P1074[3] BI: Disable additional setpoint Min: 0:0
CStat: CUT Datatype: U32 Unit: - Def: 0:0
P-Group: COMMANDS Active: first confirm QuickComm.: No Max: 4000:0
Disables additional setpoint
Index:
P1074[0] : 1st. Command data set (CDS)
P1074[1] : 2nd. Command data set (CDS)
P1074[2] : 3rd. Command data set (CDS)
Common Settings:
722.0 = Digital input 1 (requires P0701 to be set to 99, BICO)
722.1 = Digital input 2 (requires P0702 to be set to 99, BICO)
722.2 = Digital input 3 (requires P0703 to be set to 99, BICO)
722.3 = Digital input 4 (requires P0704 to be set to 99, BICO)
722.4 = Digital input 5 (requires P0705 to be set to 99, BICO)
722.5 = Digital input 6 (requires P0706 to be set to 99, BICO)
722.6 = Digital input 7 (via analog input 1, requires P0707 to be set to 99)
722.7 = Digital input 8 (via analog input 2, requires P0708 to be set to 99))
P1075[3] CI: Additional setpoint Min: 0:0
CStat: CT Datatype: U32 Unit: - Def: 0:0
P-Group: SETPOINT Active: first confirm QuickComm.: No Max: 4000:0
Defines source of the additional setpoint (to be added to main setpoint).
Index:
P1075[0] : 1st. Command data set (CDS)
P1075[1] : 2nd. Command data set (CDS)
P1075[2] : 3rd. Command data set (CDS)
Common Settings:
755 = Analog input 1 setpoint
1024 = Fixed frequency setpoint
1050 = Motor potentiometer (MOP) setpoint
Level
3
Level
3
Level
3
Level
3
