Issue 01/06 Parameter Description
MICROMASTER 440 Parameter List
6SE6400-5BB00-0BP0
187
P1781[3] Tn of Rs-adaption Min: 10
CStat: CUT Datatype: U16 Unit: ms Def: 100
P-Group: CONTROL Active: Immediately QuickComm.: No Max: 2000
Enters Rs-adaptation controller integral time.
Index:
P1781[0] : 1st. Drive data set (DDS)
P1781[1] : 2nd. Drive data set (DDS)
P1781[2] : 3rd. Drive data set (DDS)
r1782 Output of Rs-adaptation Min: -
Datatype: Float Unit: % Def: -
P-Group: CONTROL Max: -
Displays stator resistance adaptation from controller in [%] relative to rated motor resistance.
Stator resistance is obtained as a function of the motor temperature as:
: P0625 act ≈ ϑ
% 100
r1782 - r0370
Z R R R
N
sss
adaptStartact
⋅=+=
with
(P0625)R R s
s
Start
=
: r0633 act = ϑ
% 100
r1782 - r0395
Z R (r0633)R R
N
s
s
s
adaptact
⋅=+=
a)
b)
Note:
% 100 <=>
0305P3
0304P
I 3
V
Z
N
N
N
⋅
=
⋅
=
Rated motor impedance:
P1786[3] Tn of Xm-adaption Min: 10
CStat: CUT Datatype: U16 Unit: ms Def: 100
P-Group: CONTROL Active: Immediately QuickComm.: No Max: 2000
Enters Xm-adaptation controller integral time.
Index:
P1786[0] : 1st. Drive data set (DDS)
P1786[1] : 2nd. Drive data set (DDS)
P1786[2] : 3rd. Drive data set (DDS)
r1787 Output of Xm-adaption Min: -
Datatype: Float Unit: % Def: -
P-Group: CONTROL Max: -
Displays main reactance adaptation from controller in [%] relative to rated impedance.
For
N f f ≤
is valid
% 100
r1787 - r0382
Z X X X
N
mmm
adaptStartact
⋅=+=
ΓΓΓ
Note:
% 100 <=>
0305P3
0304P
I 3
V
Z
N
N
N
⋅
=
⋅
=
Rated motor impedance:
Level
4
Level
3
Level
4
Level
3
