Technical specifications
A.5 CPU 1212C
S7-1200 Programmable controller
System Manual, V4.2, 09/2016, A5E02486680-AK
1389
Technical data
CPU 1212C AC/DC/Relay
and DC/DC/Relay
CPU 1212C
DC/DC/DC
Switching delay (Qa.4 to Qa.5) 10 ms max. 5 μs max., off to on
20 μs max., on to off
Maximum relay switching frequency
1 Hz
--
Pulse Train Output rate Not recommended
2
100 kHz (Qa.0 to Qa.3)
3
, 2 Hz min.
20 kHz (Qa.4 to Qa.5)
3
Lifetime mechanical (no load)
10,000,000 open/close cycles
--
Lifetime contacts at rated load
100,000 open/close cycles
--
Behavior on RUN to STOP Last value or substitute value
(default value 0)
Last value or substitute value (default
value 0)
Number of outputs on simultaneously 3 (no adjacent points) at 60 °C horizontal or 50 °C vertical
6 at 55 °C horizontal, or 45 °C vertical
Cable length (meters) 500 m shielded,
150 m unshielded
1
Relay group-to-group isolation separates line voltage from SELV/PELV and separates different phases up to 250 V AC
line to ground.
2
For CPU models with relay outputs, you must install a digital signal board (SB) to use the pulse outputs.
3
Depending on your pulse receiver and cable, an additional load resistor (at least 10% of rated current) may improve
pulse signal quality and noise immunity.
