Note
Preventing CPU interference from antennas
CPU interference can occur if antenna proximity is too close, or if
you do not use
recommended antennas. For recommended antennas, refer to Antenna ANT794
-4MR for
LTE/UMTS/GSM Compact Operating Instructions
(
https://support.industry.siemens.com/cs/ww/en/view/23119005) (available in English and
German only).
A.16.2.2
GSM/GPRS antenna ANT794-4MR
Technical specifications of the ANT794-4MR GSM/GPRS antenna
ANT794-4MR
Article number
6NH9860-1AA00
Mobile wireless networks
GSM/GPRS
Frequency ranges
• 824 to 960 MHz (GSM 850, 900)
• 1 710 to 1 880 MHz (GSM 1 800)
• 1 900 to 2 200 MHz (GSM / UMTS)
Characteristics
omnidirectional
Antenna gain
0 dB
Impedance
50 ohms
Standing wave ratio (SWR)
< 2,0
Max. power
20 W
Polarity
linear vertical
Connector
SMA
Length of antenna cable
5 m
External material
Hard PVC, UV-resistant
Degree of protection
IP20
Permitted ambient conditions
• Operating temperature
• Transport/storage temperature
• Relative humidity
• -40 °C through +70 °C
• -40 °C through +70 °C
• 100 %
External material
Hard PVC, UV-resistant
Construction Antenna with 5 m fixed cable and SMA male
connector
Dimensions (D x H) in mm
25 x 193
Weight
• Antenna incl. cable
• Fittings
• 310 g
• 54 g
Installation
With supplied bracket
