Siemens SIMATIC S7-1200

Technical specifications
A.13 Digital signal boards (SBs)
S7-1200 Programmable controller
1508 System Manual, V4.2, 09/2016, A5E02486680-AK
Table A- 200 Connector pin locations for SB 1223 DI 2 x 5 V DC / DQ 2 x 5 V DC, 200 kHz (6ES7223-
3AD30-0XB0)
Pin
X19
1
L+ / 5 V DC
2 M / 5 V DC
3
DI e.0
4
DI e.1
5
DQ e.0
6
DQ e.1
A.13.4
SB 1223 2 X 24 V DC input / 2 X 24 V DC output specifications
Table A- 201 General specifications
Technical Data
SB 1223 DI 2 x 24 V DC, DQ 2 x 24 V DC
Article number
6ES7223-0BD30-0XB0
Dimensions W x H x D (mm)
38 x 62 x 21
Weight
40 grams
Power dissipation
1.0 W
Current consumption (SM Bus)
50 mA
Current consumption (24 V DC)
4 mA / Input used
Table A- 202 Digital inputs
Technical Data
SB 1223 DI 2 x 24 V DC, DQ 2 x 24 V DC
Number of inputs
2
Type
IEC Type 1 sink
Rated voltage
24 V DC at 4 mA, nominal
Continuous permissible voltage
30 V DC, max.
Surge voltage
35 V DC for 0.5 sec.
Logic 1 signal (min.)
15 V DC at 2.5 mA
Logic 0 signal (max.)
5 V DC at 1 mA
HSC clock input rates (max.) Single phase: 30 kHz (15 to 26 V DC)
Quadrature phase: 20 kHz (15 to 26 V DC)
Isolation (field side to logic) 707 V DC (type test)
Isolation groups
1
Filter times
us settings
0.1, 0.2, 0.4, 0.8, 1.6, 3.2, 6.4,10.0, 12.8, 20.0
ms settings
0.05, 0.1, 0.2, 0.4, 0.8, 1.6, 3.2, 6.4, 10.0, 12.8, 20.0
Number of inputs on simultaneously
2
Cable length (meters)
500 shielded, 300 unshielded
