Siemens SIMATIC S7-1200

Technical specifications
A.7 CPU 1215C
S7-1200 Programmable controller
System Manual, V4.2, 09/2016, A5E02486680-AK
1409
A.7
CPU 1215C
A.7.1
General specifications and features
Table A- 66 General
Technical data
CPU 1215C
AC/DC/Relay
CPU 1215C
DC/DC/Relay
CPU 1215C
DC/DC/DC
Article number
6ES7215-1BG40-0XB0
6ES7215-1HG40-0XB0
6ES7215-1AG40-0XB0
Dimensions W x H x D (mm) 130 x 100 x 75
Shipping weight
585 grams
550 grams
520 grams
Power dissipation 14 W 12 W
Current available (SM and CM bus)
1600 mA max. (5 V DC)
Current available (24 V DC)
400 mA max. (sensor power)
Digital input current consumption
(24 V DC)
4 mA/input used
Table A- 67 CPU features
Technical data
Description
User memory
(Refer to "General
technical specifica-
tions
(Page 1359)",
"Internal CPU
memory reten-
tion".)
Work
125 Kbytes
Load
4 Mbytes, internal, expandable up to SD card size
Retentive 10 Kbytes
On-board digital I/O
14 inputs/10 outputs
On-board analog I/O
2 inputs/2 outputs
Process image size
1024 bytes of inputs (I)/1024 bytes of outputs (Q)
Bit memory (M)
8192 bytes
Temporary (local) memory
• 16 Kbytes for startup and program cycle (including associated FBs and FCs)
• 6 Kbytes for each of the other interrupt priority levels (including FBs and FCs)
Signal modules expansion
8 SMs max.
SB, CB, BB expansion
1 max.
Communication module expansion
3 CMs max.
High-speed counters Up to 6 configured to use any built-in or SB inputs. Refer to "Hardware input pin
assignment" (Page 580) for CPU 1215C: HSC default address assignments.
• 100/
1
80 kHz (Ia.0 to Ia.5)
• 30/
1
20 kHz (Ia.6 to Ib.5)
