Siemens SIMATIC S7-1200 - A.16.2.3 Flat antenna ANT794-3 M

To Next Page

To Previous Page

Technical specifications

A.16 Communication interfaces

S7-1200 Programmable controller

System Manual, V4.2, 09/2016, A5E02486680-AK

1537

A.16.2.3

Flat antenna ANT794-3M

Technical specifications of the flat antenna ANT794-3M

ANT794-3M

Article number

6NH9870-1AA00

Mobile wireless networks

GSM 900

GSM 1800/1900

Frequency ranges

890 - 960 MHz

1710 - 1990 MHz

Standing wave ratio (VSWR) ≤ 2:1 ≤ 1,5:1

Return loss (Tx)

≈ 10 dB

≈ 14 dB

Antenna gain 0 dB

Impedance

50 ohms

Max. power

10 W

Antenna cable

HF cable RG 174 (fixed) with SMA male connector

Cable length

1.2 m

Degree of protection

IP64

Permitted temperature range

-40 °C to +75 °C

Flammability

UL 94 V2

External material

ABS Polylac PA-765, light gray (RAL 7035)

Dimensions (W x L x H) in mm

70.5 x 146.5 x 20.5

Weight

130 g
