Siemens SIMATIC S7-1200

Technical specifications
A.13 Digital signal boards (SBs)
S7-1200 Programmable controller
1502 System Manual, V4.2, 09/2016, A5E02486680-AK
Table A- 189 Connector pin locations for SB 1221 DI 4 x 5 V DC, 200 kHz (6ES7221-3AD30-0XB0)
Pin
X19
1
L+ / 5 V DC
2 M / 5 V DC
3
DI e.0
4 DI e.1
5
DI e.2
6
DI e.3
A.13.2
SB 1222 200 kHz digital output specifications
Table A- 190 General specifications
Technical data
SB 1222 DQ 4 x 24 V DC, 200 kHz
SB 1222 DQ 4 x 5 V DC, 200 kHz
Article number
6ES7222-1BD30-0XB0
6ES7222-1AD30-0XB0
Dimensions W x H x D (mm)
38 x 62 x 21
Weight
35 grams
Power dissipation
0.5 W
Current consumption (SM Bus)
35 mA
Current consumption (24 V DC)
15 mA
Table A- 191 Digital outputs
Technical data
SB 1222 DQ 4 x 24 V DC, 200 kHz
SB 1222 DQ 4 x 5 V DC, 200 kHz
Number of outputs
4
Output type
Solid state - MOSFET sink and source
1
Voltage range
20.4 to 28.8 V DC
4.25 to 6.0 V DC
Logic 1 signal at max. current
L+ minus 1.5 V
L+ minus 0.7 V
Logic 0 signal at max. current
1.0 V DC, max.
0.2 V DC, max.
Current (max.)
0.1 A
Lamp load
--
On state contact resistance
11 Ω max.
7 Ω max.
Off state resistance
6 Ω max.
0.2 Ω max.
Leakage current per point
--
Pulse Train Output rate 200 kHz max., 2 Hz min.
Surge current
0.11 A
Overload protection No
Isolation (field side to logic)
707 V DC (type test)
Isolation groups
1
Currents per common
0.4 A
Inductive clamp voltage
Non
