Table A- 194 Connector pin locations for SB 1222 DQ 4 x 5 V DC, 200 kHz (6ES7222-1AD30-0XB0)
Pin
X19
1
L+ / 5 V DC
2 M / 5 V DC
3
DQ e.0
4 DQ e.1
5
DQ e.2
6
DQ e.3
A.13.3
SB 1223 200 kHz digital input / output specifications
Table A- 195 General specifications
Technical data
SB 1223 DI 2 x 24 V DC /
DQ 2 x 24 V DC, 200 kHz
SB 1223 DI 2 x 5 V DC /
DQ 2 x 5 V DC, 200 kHz
Article number
6ES7223-3BD30-0XB0
6ES7223-3AD30-0XB0
Dimensions W x H x D (mm)
38 x 62 x 21
Weight
35 grams
Power dissipation
1.0 W
0.5 W
Current consumption (SM Bus)
35 mA
Current consumption (24 V DC)
7 mA / Input + 30 mA
15 mA / input + 15 mA
Table A- 196 Digital inputs
Technical data
SB 1223 DI 2 x 24 V DC /
DQ 2 x 24 V DC, 200 kHz
SB 1223 DI 2 x 5 V DC /
DQ 2 x 5 V DC, 200 kHz
Number of inputs
2
Type
Source
Rated voltage
24 V DC at 7 mA, nominal
5 V DC at 15 mA, nominal
Continuous permissible voltage
28.8 V DC
6 V DC
Surge voltage
35 V DC for 0.5 sec.
6 V
Logic 1 signal
0 V (10 mA) to L+ minus 10 V (2.9 mA)
0 V (20 mA) to L+ minus 2.0 V (5.1 mA)
Logic 0 signal
L+ minus 5 V (1.4 mA) to L+ (0 mA)
L+ minus 1.0 V (2.2 mA) to L + (0 mA)
HSC clock input rates (max.) Single phase: 200 kHz
Quadrature phase: 160 kHz
Isolation (field side to logic) 707 V DC (type test)
Isolation groups
1 (no isolation to outputs)
Filter times
us settings
0.1, 0.2, 0.4, 0.8, 1.6, 3.2, 6.4, 10.0, 12.8, 20.0
ms settings
0.05, 0.1, 0.2, 0.4, 0.8, 1.6, 3.2, 6.4, 10.0, 12.8, 20.0
Number of inputs on simultaneously
2
Cable length (meters)
50 shielded twisted pair
