C.7 Basic HMI devices
S7-1200 Programmable controller
1564 System Manual, V4.2, 09/2016, A5E02486680-AK
C.7
Basic HMI devices
Table C- 14 HMI devices
HMI Basic Panels
Article number
KTP400 Basic (Mono, PN)
6AV2123-2DB03-0AX0
KTP700 Basic 6AV2123-2GB03-0AX0
KTP700 Basic DP
6AV2123-2GA03-0AX0
KTP900 Basic 6AV2123-2JB03-0AX0
KTP1200 Basic
6AV2123-2MB03-0AX0
KTP1200 Basic DP
6AV2123-2MA03-0AX0
C.8
Spare parts and other hardware
Table C- 15 Expansion cables, simulators, and end retainers
Item
Article number
I/O expansion
cable
I/O Expansion cable, 2 mm 6ES7290-6AA30-0XA0
I/O simulator
Simulator (1211C/1212C - 8 position)
6ES7274-1XF30-0XA0
Simulator (1214C/1215C - 14 position)
6ES7274-1XH30-0XA0
Simulator, CPU 1217C
6ES7274-1XK30-0XA0
Potentiometer
module
S7-1200 Potentiometer module 6ES7274-1XA30-0XA0
Ethernet strain
relief
Single port RJ45 strain relief, 10/100 Mbit/sec
6ES7290-3AA30-0XA0
Dual port RJ45 strain relief, 10/100 Mbit/sec
6ES7290-3AB30-0XA0
Spare door kit
CPU 1211C/1212C
6ES7291-1AA30-0XA0
CPU 1214C
6ES7291-1AB30-0XA0
CPU 1215C
6ES7291-1AC30-0XA0
CPU 1217C
6ES7291-1AD30-0XA0
Signal module, 45 mm
6ES7291-1BA30-0XA0
Signal module, 70 mm 6ES7291-1BB30-0XA0
Communication module (for use with 6ES72xx-xxx32-0XB0 and
6ES72xx-xxx30-0XB0 modules)
6ES7291-1CC30-0XA0
End Retainer End Retainer Thermoplastic, 10 MM 8WA1808
End Retainer Steel, 10.3 MM
8WA1805
