A.20
S7-1200 Potentiometer module
The S7-1200 Potentiometer module is an accessory for S7-1200 CPU. Each potentiometer
creates an output voltage proportional to the position of the potentiometer to drive each of
the two CPU analog inputs 0 V DC to 10 V DC. To install the potentiometer:
1. Insert the circuit board ‘fingers’ into any S7-1200 CPU analog input terminal block, and
connect an external DC power supply to the 2-position connector on the potentiometer
module.
2. Use a small screwdriver to make the adjustments: turn the potentiometer clockwise (to
the right) to increase the voltage output, and counterclockwise (to the left) to decrease
the voltage output.
Note
Follow ESD guidelines when handling the S7
-1200 Potentiometer module.
Technical data
S7-1200 Potentiometer module
Article number
6ES7274-1XA30-0XA0
Used with CPU
All S7-1200 CPUs
Number of potentiometers
2
Dimensions W x H x D (mm)
20 x 33 x 14
Weight
26 grams
User-supplied voltage input at 2-position connector
1
(Class 2, Limited Power, or sensor power from PLC)
16.4 V DC to 28.8 V DC
Cable length (meters)/type
<30 m, shielded twisted pair
Input current consumption
10 mA max.
Potentiometer voltage output to S7-1200 CPU analog in-
puts
1
0 V DC to 10.5 V DC min.
Isolation
Not isolated
Ambient temperature range
-20 °C to 60 °C
1
Potentiometer module output voltage stability depends on the quality of the user-supplied voltage
input at the 2-position connector - consider it as an analog input voltage.
