Siemens SIMATIC S7-1200 - A.6 CPU 1214 C; A.6.1 General specifications and features

Technical specifications
A.6 CPU 1214C
S7-1200 Programmable controller
System Manual, V4.2, 09/2016, A5E02486680-AK
1395
Note
Unused analog input
s should be shorted.
A.6
CPU 1214C
A.6.1
General specifications and features
Table A- 47 General
Technical data
CPU 1214C
AC/DC/Relay
CPU 1214C
DC/DC/Relay
CPU 1214C
DC/DC/DC
Article number 6ES7214-1BG40-0XB0 6ES7214-1HG40-0XB0 6ES7214-1AG40-0XB0
Dimensions W x H x D (mm)
110 x 100 x 75
Shipping weight
475 grams
435 grams
415 grams
Power dissipation
14 W
12 W
Current available (SM and CM bus)
1600 mA max. (5 V DC)
Current available (24 V DC)
400 mA max. (sensor power)
Digital input current consumption
(24 V DC)
4 mA/input used
Table A- 48 CPU features
Technical data
Description
User memory
(Refer to "General
technical specifica-
tions",
(Page 1359) "In-
ternal CPU
memory reten-
tion".)
Work
100 Kbytes
Load
4 Mbytes internal, expandable up to SD card size
Retentive 10 Kbytes
On-board digital I/O
14 inputs/10 outputs
On-board analog I/O
2 inputs
Process image size
1024 bytes of inputs (I)/1024 bytes of outputs (Q)
Bit memory (M)
8192 bytes
Temporary (local) memory
• 16 Kbytes for startup and program cycle (including associated FBs and FCs)
• 6 Kbytes for each of the other interrupt priority levels (including FBs and FCs)
Signal modules expansion
8 SMs max.
