Ordering Information
C.8 Spare parts and other hardware
S7-1200 Programmable controller
System Manual, V4.2, 09/2016, A5E02486680-AK
1567
Table C- 17 S7-1200 SMs V3.2 and later - Terminal block spare kits
If you have
S7-1200 SMs V3.2 and later (article number)
Use this terminal block spare kit (4/pk)
Terminal block
article number
Terminal block
description
SM 1221 DI 8 x DC (6ES7221-1BF32-0XB0)
SM 1222 DQ 8 x DC (6ES7222-1BF32-0XB0)
SM 1222 DQ 8 x Relay (6ES7222-1HF32-0XB0) 6ES7292-1AG40-0XA1 7 pin, tin-plated, keyed-
SM 1238 Energy Meter 480 V AC (6ES7238-5XA32-0XB0) for
6ES7292-1AG40-0XA2 7-pin, tin-plated, keyed-
SM 1238 Energy Meter 480 V AC (6ES7238-5XA32-0XB0) for
6ES7292-1AG30-0XA0 7-pin, tin-plated
SM 1231 AI 4 x 13 bit (6ES7231-4HD32-0XB0)
SM 1232 AQ 2 x 14 bit (6ES7232-4HB32-0XB0)
SM 1231 AI 4 x TC (6ES7231-5QD32-0XB0)
SM 1231 AI 4 x 16 bit (6ES7231-5ND32-0XB0)
SM 1221 DI 16 x DC (6ES7221-1BH32-0XB0)
SM 1222 DQ 16 x DC (6ES7222-1BH32-0XB0)
SM 1222 DQ 16 x Relay (6ES7222-1HH32-0XB0) 6ES7292-1AG40-0XA0 7 pin, tin-plated, keyed-
SM 1223 DI 8 x DC/DQ 8 x DC (6ES7223-1BH32-0XB0)
SM 1223 8 x DC/8 x Relay (6ES7223-1PH32-0XB0)
6ES7292-1AG40-0XA0 7 pin, tin-plated, keyed-
SM 1223 8 x AC/8 x Relay (6ES7223-1QH32-0XB0) 6ES7292-1AG40-0XA0 7 pin, tin-plated, keyed-
right
SM 1234 AI 4 / AQ 2 (6ES7234-4HE32-0XB0)
SM 1231 AI 8 x 13 BIT (6ES7231-4HF32-0XB0)
SM 1232 AQ 4 x 14 bit (6ES7232-4HD32-0XB0)
SM 1231 AI 4 x RTD (6ES7231-5PD32-0XB0)
SM 1231 AI 8 x TC (6ES7231-5QF32-0XB0)
SM 1278 IO LINK (6ES7278-4BD32 0XB0)
SM 1222 DQ 8 x Relay (Changeover) (6ES7222-1XF32-0XB0)
SM 1223 DI 16 x DC/DQ 16 x DC (6ES7223-1BL32-0XB0)
SM 1223 DI 16 x DC/DQ 16 x Relay (6ES7223-1PL32-0XB0)
11 pin, tin-plated, keyed
SM 1231 AI 8 x RTD (6ES7231-5PF32-0XB0)
