Device exchange and spare parts compatibility
D.2 S7-1200 V3.0 and earlier terminal block spare kits
S7-1200 Programmable controller
System Manual, V4.2, 09/2016, A5E02486680-AK
1579
Table D- 2 S7-1200 SMs V3.0 and earlier - Terminal Block spare kits
If you have
S7-1200 SM V3.0 and earlier (article number)
Use this terminal block spare kit (4/pk)
Terminal block article number
Terminal block description
SM 1221 DI 8 x DC (6ES7221-1BF30-0XB0)
6ES7292-1AG30-0XA0 7 pin, tin-plated
SM 1222 DQ 8 x DC (6ES7222-1BF30-0XB0)
SM 1222 DQ 8 x Relay (6ES7222-1HF30-0XB0)
SM 1231 AI 4 x 13 bit (6ES7231-4HD30-0XB0)
6ES7292-1BG30-0XA0 7 pin, gold-plated
SM 1232 AQ 2 x 14 bit (6ES7232-4HB30-0XB0)
SM 1231 AI 4 x TC (6ES7231-5QD30-0XB0)
SM 1231 AI 4 x 16 bit (6ES7231-5ND30-0XB0)
SM 1221 DI 16 x DC (6ES7221-1BH30-0XB0)
6ES7292-1AG30-0XA0 7 pin, tin-plated
SM 1222 DQ 16 x DC (6ES7222-1BH30-0XB0)
SM 1222 DQ 16 x Relay (6ES7222-1HH30-0XB0)
SM 1223 DI 8 x DC/DQ 8x DC (6ES7223-1BH30-0XB0)
SM 1223 8 x DC/8 x Relay (6ES7223-1PH30-0XB0)
SM 1223 8 x AC/8 x Relay (6ES7223-1QH30-0XB0)
SM 1234 AI 4 / AQ 2 (6ES7234-4HE30-0XB0)
6ES7292-1BG30-0XA0 7 pin, gold-plated
SM 1231 AI 8 x 13 bit (6ES7231-4HF30-0XB0)
SM 1232 AQ 4 x 14 bit (6ES7232-4HD30-0XB0)
SM 1231 AI 4 x RTD (6ES7231-5PD30-0XB0)
SM 1231 AI 8 x TC (6ES7231-5QF30-0XB0)
SM 1222 DQ 8 x Relay (Changeover)
(6ES7222-1XF30-0XB0)
6ES7292-1AL30-0XA0 11 pin, tin-plated
SM 1223 DI 16 x DC/DQ 16 x DC (6ES7223-1BL30-
0XB0)
SM 1223 16 x DC/16 x Relay (6ES7223-1PL30-0XB0)
SM 1231 AI 8 x RTD (6ES7231-5PF30-0XB0) 6ES7292-1BL30-0XA0 11 pin, gold-plated
