Extended instructions
9.7 Diagnostics (PROFINET or PROFIBUS)
S7-1200 Programmable controller
System Manual, V4.2, 09/2016, A5E02486680-AK
457
Note
When using the dropdown to make your selections for configuring the tag to the DATA
parameter, select the DB (in the example, "Datablock") and the tag (in the example,
"String[ ]"). In order to read the entire String data type,
you must delete the brackets
so that the final result is: "Datablock".String
– Define PLC tags (memory area, flags) for the output parameters of the instruction.
