Extended instructions
9.9 Recipes and Data logs
S7-1200 Programmable controller
System Manual, V4.2, 09/2016, A5E02486680-AK
505
A recipe DB that contains a structure which is consistent with the CSV file data structure
must exist, before a recipe import operation is possible.
CSV file rules:
● The CSV file must be located in the root directory "Recipes" folder of internal load
memory or external load memory, if an optional external "program" memory card is
installed.
● The name of the CSV file must match the name of the data block at the RECIPE_DB
parameter.
● The first line (header) of the CSV file contains the name of the recipe components. The
first line is ignored during import. The names of the recipe components in the CSV file
and the data block are not reconciled during the import process.
● In each case the first value in each line of the CSV file is the index number of the recipe.
The individual recipes are imported in the order of the index. For this, the index in the
CSV file has to be in ascending order and may contain no gaps (if this is not the case, the
error message 80B0 is output at the STATUS parameter).
● The CSV file may not contain more recipe data records than provided for in the recipe
data block. The maximum number of data records is indicated by the array limits in the
data block.
Table 9- 199 Values of ERROR and STATUS
ERROR
STATUS
(W#16#....)
Description
0
0000
No error
0 7000 Call with no REQ edge: BUSY = 0, DONE = 0
0
7001
First call with REQ edge (working): BUSY = 1, DONE = 0
0
7002
N
th
call (working): BUSY = 1, DONE = 0
1
8070
All instance memory is in use.
1
8090
The file name contains invalid characters.
1 8092 No matching CSV file found for the import. Possible cause: The name of the CSV file
does not match the name of the recipe DB.
1
80C0
CSV file is temporarily locked.
1
80C1
Data block is temporarily locked.
1 80B0 Numbering in the index of the CSV file is not c
ontinuous, not ascending or exceeds the
maximum number (array limit) in the data block.
1 80B1
Structure of the recipe data block and the CSV file do not match: The CSV file contains
too many fields.
1 80B2 Structure of the recipe data block and the CSV
file do not match: The CSV file contains
too few fields.
1
80B6
Recipe DB attribute "Only store in load memory" is not enabled.
1 80D0 +n Structure of the recipe data block and the CSV file do not match: Data type in field n
does not match (n<=46).
1 80FF Structure of the recipe data block and the CSV file do not match: Data type in field n
does not match (n>46).
