Extended instructions
9.10 Data block control
S7-1200 Programmable controller
System Manual, V4.2, 09/2016, A5E02486680-AK
537
Parameter RET_VAL
Error code*
(W#16#...)
Description
0000
No error
0081 The destination area is greater than the source area.
The source area is written completely to the destination area. The remaining bytes of the destination area
remain unchanged.
7000
First call with REQ = 0: No data transfer active; BUSY has the value "0".
7001
First call with REQ = 1: Data transfer triggered; BUSY has the value "1".
7002
Intermediate call (REQ irrelevant): Data transfer already active; BUSY has the value "1".
8081 The source area is larger than the destination area.
The complete destination area is written. The remaining bytes of the source area are ignored.
8092 The "Create data block" function is currently unavailable because
• The "Compress user memory" function is currently active.
• The maximum number of blocks on your CPU has already been reached.
8093
No data block or a data block that is not in the work memory is specified for the SRCBLK parameter.
8094
An invalid value was specified at parameter ATTRIB.
80A1 DB number error:
• The number is "0"
• The number exceeds the CPU-specific high limit for DB numbers
• Low limit > high limit
80A2 DB length error:
• The length is "0"
• The length is an odd number
• The length is greater than permitted by the CPU
80A3
The data block at the SRCBLK parameter was not created with standard access.
80B1
There is no DB number free.
80B2
Not enough work memory.
80B4
The memory card is write-protected.
80BB
Not enough load memory.
80C3
The maximum number of simultaneously active "CREATE_DB" instructions has already been reached.
General error
information
See also: Common error codes for the Extended instructions (Page 553)
* You can display the error code as either integer or hexadecimal values in the program editor.
