RM0440 Rev 4 2065/2126
RM0440 USB Type-C™ / USB Power Delivery interface (UCPD)
2079
46.7.3 UCPD control register (UCPD_CR)
Address offset: 0x00C
Reset value: 0x0000 0000
Writing to this register is only effective when the peripheral is enabled (UCPDEN = 1).
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
WUPEN
FORCECLK
RXFILT2N3
RXFILTDIS
rw rw rw rw
Bits 31:4 Reserved, must be kept at reset value.
Bit 3 WUPEN: Wakeup from Stop mode enable
Setting the bit enables the UCPD_ASYNC_INT signal.
0: Disable
1: Enable
Bit 2 FORCECLK: Force ClkReq clock request
0: Do not force clock request
1: Force clock request
Bit 1 RXFILT2N3: BMC decoder Rx pre-filter sampling method
Number of consistent consecutive samples before confirming a new value.
0: 3 samples
1: 2 samples
Bit 0 RXFILTDIS: BMC decoder Rx pre-filter enable
0: Enable
1: Disable
The sampling clock is that of the receiver (that is, after pre-scaler).
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res.RE Res. Res. Res. Res. Res. Res. Res. Res. Res.
CC2TCDIS CC1TCDIS
Res.
RDCH
FRSTX
FRSRXEN
rw rw rw rs rw
1514131211109876543210
Res. Res. Res. Res.
CCENABLE[1:0]
ANAMODE
ANASUBMODE[1:0]
PHYCCSEL
PHYRXEN
RXMODE
TXHRST
TXSEND
TXMODE[1:0]
rw rw rw rw rw rw rw rw rs rs rw rw
