RM0440 Rev 4 767/2126

RM0440 Digital-to-analog converter (DAC)

773

Note: It represents the number of LSI/LSE clocks to perform a sample phase. Sampling time =

(TSAMPLE1[9:0] + 1) x LSI/LSE clock period.

22.7.18 DAC channel2 sample and hold sample time register

(DAC_SHSR2)

This register is available only on dual-channel DACs. Refer to Section 22.3: DAC

implementation.

Address offset: 0x44

Reset value: 0x0000 0000

Note: It represents the number of LSI/LSE clocks to perform a sample phase. Sampling time =

(TSAMPLE1[9:0] + 1) x LSI/LSE clock period.

22.7.19 DAC sample and hold time register (DAC_SHHR)

Address offset: 0x48

Reset value: 0x0001 0001

Bits 31:10 Reserved, must be kept at reset value.

Bits 9:0 TSAMPLE1[9:0]: DAC channel1 sample time (only valid in Sample and hold mode)

These bits can be written when the DAC channel1 is disabled or also during normal operation.

in the latter case, the write can be done only when BWST1 of DAC_SR register is low, If

BWST1=1, the write operation is ignored.

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.

1514131211109876543210

Res. Res. Res. Res. Res. Res. TSAMPLE2[9:0]

rw rw rw rw rw rw rw rw rw rw

Bits 31:10 Reserved, must be kept at reset value.

Bits 9:0 TSAMPLE2[9:0]: DAC channel2 sample time (only valid in Sample and hold mode)

These bits can be written when the DAC channel2 is disabled or also during normal

operation. in the latter case, the write can be done only when BWST2 of DAC_SR register is

low, if BWST2=1, the write operation is ignored.

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

Res. Res. Res. Res. Res. Res. THOLD2[9:0]

rw rw rw rw rw rw rw rw rw rw

1514131211109876543210

Res. Res. Res. Res. Res. Res. THOLD1[9:0]

rw rw rw rw rw rw rw rw rw rw
