261
5 Setup Data
5.4 Setup2 Editor
Yarn data The yarn data are necessary for the calculation of the yarn consumption.
Further information:
Helpers for Input [-> 239]
File tools [-> 245]
Table Tools [-> 244]
Setup Data [-> 233]
Overview of the Setup2 Editor of the CMS [-> 237]
Comparing Setup1 to Setup2 [-> 235]
Explanation
"Wheel" right device: Select measuring wheel (n=1 to 8).
left device: Select measuring wheel (n=9 to 16).
"Y" Select the yarn carrier (1A to 8D) working with this measuring
wheel.
"Yarn Quality"
for yarn
disposition only
"Yarn"
A maximum of 3 yarns can be threaded into one measuring
wheel. The yarn data is entered in a separate line for each yarn.
"Yarn Quality"
Example:
Enter 28 here
"Number of Yarn Threads"
Enter the number of individual threads.
Enter 2 here
"Number of Threads "
Enter the number of threads per yarn carrier here
NM; TEX; DTEX; NE/C; NE/W; DEN
Select unit for the yarn thickness.
Enter NM here
"Yarn ID" Yarn ID or comment
