7 Repairing the knitting machine
7.3 Replacing parts
This chapter contains information on:
Remove the carriage part to replace the cams [-> 317]
Remove the carriage part when the carriage assembly is blocked in the
needle bed [-> 320]
Assembling carriage part and carriage support [-> 324]
Remove the carriage part to
replace the cams
1. Move the carriage assembly outward up to the support surface.
2. Switch off 40 V power supply.
3. Open the covers.
4. Move the yarn carrier from the clamping and cutting area into the needle
bed.
Reason: When lifting the carriage part, the yarn carriers can be
damaged.
Key Function
Call up "Manual interventions" window
Confirm the repair
Call up "Machine start" window
Call up "Main menu"
Keys for removing the carriage part
