TP-Link T1600G-52PS Cli Reference Guide

136
17.14 copy running-config startup-config
Description
The copy running-config startup-config command is used to save the
current settings.
Syntax
copy running-config startup-config
Command Mode
Privileged EXEC Mode
Privilege Requirement
Only Admin and Operator level users have access to these commands.
Example
Save current settings:
T1600G-52TS# copy running-config startup-config
17.15 copy startup-config tftp
Description
The copy startup-config tftp command is used to backup the configuration
file to TFTP server.
Syntax
copy startup-config tftp ip-address ip-addr filename name
Parameter
ip-addr —— IP Address of the TFTP server. Both IPv4 and IPv6 addresses are
supported, for example 192.168.0.1 or fe80::1234.
name —— Specify the name for the configuration file which would be backup.
Command Mode
Privileged EXEC Mode
Privilege Requirement
Only Admin and Operator level users have access to these commands.
Example
Backup the configuration files to TFTP server with the IP 192.168.0.148 and
name this file config.cfg:

TP-Link T1600G-52PS Specifications

General

PoE Ports	48
Switching Capacity	104 Gbps
Forwarding Rate	77.4Mpps
PoE Budget	384 W
Power Supply	AC 100-240V, 50/60Hz
Mounting	Rack Mountable
MAC Address Table	16K
Jumbo Frame	9KB
Packet Buffer Memory	4 MB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 90% non-condensing
Layer	Layer 2+
Dimensions (W x D x H)	440 x 44 x 44 mm
Standards and Protocols	IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at
Quality of Service	8 queues per port
VLAN	4K VLANs
Management	Web-based, SNMP
Security	802.1X
Ports	48 x 10/100/1000 Mbps RJ45 ports, 4 x 1G SFP slots
