198
Syntax
power profile
name
[ supply { enable | disable } [ priority { low | middle | high }
[ consumption {
power-limit
| auto | class1 | class2 | class3 | class4 } ] ] ]
no power profile
name
Parameter
name
—— The PoE profile name, ranging from 1 to 16 characters. If the name
being assigned contains spaces then put it inside double quotes.
supply —— The PoE status of the port in the profile. By default, the PoE
status is “enable”.
priority —— The PoE priority of the port in the profile. The priority levels
include “high”, “middle” and “low” in descending order. When the supply
power exceeds the system power limit, the PD linked to the port with lower
priority will be disconnected. By default, the PoE priority is “low”.
consumption
—— The max power the port in the profile can supply. There are
six options: “power-limit”, “auto”, ”class1”, “class2”, “class3” and “class4”.
“power-limit” indicates you can manually enter a value. It ranges from 1 to 300.
The value is in the unit of 0.1 watt. For instance, if you want to configure the
max power as 5w, you should enter 50. “auto” indicates the value is assigned
automatically by the PoE switch. “class1” represents 4w. “class2” represents
7w. “class3” represents 15.4w. “class4” represents 30w.
Command Mode
Global Configuration Mode
Example
Create a PoE profile named “IP Camera” whose PoE status is “enable”, PoE
priority is “low” and the power limit is “5w”:
T1600G-52PS(config)# power profile “IP Camera” supply enable priority
low consumption 50
25.3 power time-range
Description
The power time-range command is used to create PoE time-range for the
switch and enter Power Time-range Configuration Mode. After a PoE
time-range is created, you need to specify the date and time which has three
mode options: absolute, periodic and holiday. A PoE time-range is the
intersection of absolute time-range and periodic time-range with holiday
