TP-Link T1600G-52PS Cli Reference Guide

63
9.9 ip http secure-server download certificate
Description
The ip http secure-server download certificate command is used to
download a certificate to the switch from TFTP server.
Syntax
ip http secure-server download certificate ssl-cert ip-address ip-addr
Parameter
ssl-cert —— The name of the SSL certificate which is selected to download
to the switch. The length of the name ranges from 1 to 25 characters. The
Certificate must be BASE64 encoded.
ip-addr —— The IP address of the TFTP server. Both IPv4 and IPv6 addresses
are supported, for example 192.168.0.1 or fe80::1234.
Command Mode
Global Configuration Mode
Privilege Requirement
Only Admin, Operator and Power User level users have access to these
commands.
Example
Download an SSL Certificate named ssl-cert from TFTP server with the IP
address of 192.168.0.146:
T1600G-52TS(config)# ip http secure-server download certificate ssl-cert
ip-address 192.168.0.146
Download an SSL Certificate named ssl-cert from TFTP server with the IP
address of fe80::1234
T1600G-52TS(config)# ip http secure-server download certificate ssl-cert
ip-address fe80::1234

TP-Link T1600G-52PS Specifications

General

PoE Ports	48
Switching Capacity	104 Gbps
Forwarding Rate	77.4Mpps
PoE Budget	384 W
Power Supply	AC 100-240V, 50/60Hz
Mounting	Rack Mountable
MAC Address Table	16K
Jumbo Frame	9KB
Packet Buffer Memory	4 MB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 90% non-condensing
Layer	Layer 2+
Dimensions (W x D x H)	440 x 44 x 44 mm
Standards and Protocols	IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at
Quality of Service	8 queues per port
VLAN	4K VLANs
Management	Web-based, SNMP
Security	802.1X
Ports	48 x 10/100/1000 Mbps RJ45 ports, 4 x 1G SFP slots
