212
default, it is automatic. It ranges from o to 2000000. By default, it is 0 which is
mean auto.
portfast —— Enable/ Disable Edge Port. By default, it is disabled. The edge
port can transit its state from blocking to forwarding rapidly without waiting
for forward delay.
point-to-point —— The P2P link status, with auto, open and close options. By
default, the option is auto. If the two ports in the P2P link are root port or
designated port, they can transit their states to forwarding rapidly to reduce
the unnecessary forward delay.
Command Mode
Interface Configuration Mode (interface gigabitEthernet / interface range
gigabitEthernet / interface port-channel / interface range port-channel)
Privilege Requirement
Only Admin, Operator and Power User level users have access to these
commands.
Example
Enable the STP function of port 1, and configure the Port Priority as 64,
ExtPath Cost as 100, IntPath Cost as 100, and then enable Edge Port:
T1600G-52TS(config)# interface gigabitEthernet 1/0/1
T1600G-52TS(config-if)# spanning-tree common-config port-priority 64
ext-cost 100 int-cost 100 portfast enable point-to-point open
26.5 spanning-tree mode
Description
The spanning-tree mode command is used to configure the STP mode of the
switch. To return to the default configurations, please use no spanning-tree
mode command.
Syntax
spanning-tree mode { stp | rstp | mstp }
no spanning-tree mode
Parameter
stp ——Spanning Tree Protocol, the default value.
rstp ——Rapid Spanning Tree Protocol
mstp ——Multiple Spanning Tree Protocol
