TP-Link T1600G-52PS Cli Reference Guide

245
Example
Configure the filtering mode of profile 1 as deny:
T1600G-52TS(config)# ip igmp profile 1
T1600G-52TS(config-igmp-profile)#deny
27.22 permit
Description
The permit command is used to configure the filtering mode of profile as
permit.
Syntax
permit
Command Mode
Profile Configuration Mode
Privilege Requirement
Only Admin, Operator and Power User level users have access to these
commands.
Example
Configure the filtering mode of profile 1 as permit:
T1600G-52TS(config)# ip igmp profile 1
T1600G-52TS(config-igmp-profile)#permit
27.23 range
Description
The range command is used to configure the range of the profile’s filtering
multicast address. To delete the corresponding filtering multicast address,
please use no range command. A profile contains 16 filtering IP-range entries
at most.
Syntax
range start-ip end-ip
no range start-ip end-ip

TP-Link T1600G-52PS Specifications

General

PoE Ports	48
Switching Capacity	104 Gbps
Forwarding Rate	77.4Mpps
PoE Budget	384 W
Power Supply	AC 100-240V, 50/60Hz
Mounting	Rack Mountable
MAC Address Table	16K
Jumbo Frame	9KB
Packet Buffer Memory	4 MB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 90% non-condensing
Layer	Layer 2+
Dimensions (W x D x H)	440 x 44 x 44 mm
Standards and Protocols	IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at
Quality of Service	8 queues per port
VLAN	4K VLANs
Management	Web-based, SNMP
Security	802.1X
Ports	48 x 10/100/1000 Mbps RJ45 ports, 4 x 1G SFP slots
