TP-Link T1600G-52PS Cli Reference Guide

297
Chapter 30 LLDP Commands
LLDP function enables network devices to advertise their own device information periodically
to neighbors on the same LAN. The information of the LLDP devices in the LAN can be stored
by its neighbor in a standard MIB, so it is possible for the information to be accessed by a
Network Management System (NMS) such as SNMP.
30.1 lldp
Description
The lldp command is used to enable LLDP function. To disable the LLDP
function, please use no lldp command.
Syntax
lldp
no lldp
Command Mode
Global Configuration Mode
Privilege Requirement
Only Admin, Operator and Power User level users have access to these
commands.
Example
Enable LLDP function globally:
T1600G-52TS(config)#lldp
30.2 lldp hold-multiplier
Description
The lldp hold-multiplier command is used to configure the Hold Multiplier
parameter. The aging time of the local information in the neighbor device is
determined by the actual TTL value used in the sending LLDPDU. TTL = Hold
Multiplier * Transmit Interval. To return to the default configuration, please
use no lldp hold-multiplier command.
Syntax
lldp hold-multiplier multiplier
no lldp hold-multiplier

TP-Link T1600G-52PS Specifications

General

PoE Ports	48
Switching Capacity	104 Gbps
Forwarding Rate	77.4Mpps
PoE Budget	384 W
Power Supply	AC 100-240V, 50/60Hz
Mounting	Rack Mountable
MAC Address Table	16K
Jumbo Frame	9KB
Packet Buffer Memory	4 MB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 90% non-condensing
Layer	Layer 2+
Dimensions (W x D x H)	440 x 44 x 44 mm
Standards and Protocols	IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at
Quality of Service	8 queues per port
VLAN	4K VLANs
Management	Web-based, SNMP
Security	802.1X
Ports	48 x 10/100/1000 Mbps RJ45 ports, 4 x 1G SFP slots
