TP-Link T1600G-52PS Cli Reference Guide

28
Chapter 4 MAC-based VLAN Commands
MAC VLAN (Virtual Local Area Network) is the way to classify the VLANs based on MAC
Address. A MAC address is relative to a single VLAN ID. The untagged packets and the
priority-tagged packets coming from the MAC address will be tagged with this VLAN ID.
4.1 mac-vlan mac-address
Description
The mac-vlan mac-address command is used to create a MAC-based VLAN
entry. To delete a MAC-based VLAN entry, please use the no mac-vlan
mac-address command.
Syntax
mac-vlan mac-address mac-addr vlan vlan-id [description descript ]
no mac-vlan mac-address
mac-addr
Parameter
mac-addr —— MAC address, in the format of XX:XX:XX:XX:XX:XX.
vlan-id —— Specify IEEE 802.1Q VLAN ID, ranging from 1 to 4094.
descript —— Give a description to the MAC address for identification, which
contains 8 characters at most.
Command Mode
Global Configuration Mode
Privilege Requirement
Only Admin, Operator and Power User level users have access to these
commands.
Example
Create VLAN 2 with the MAC address 00:11:11:01:01:12 and the name “TP”:
T1600G-52TS(config)#mac-vlan mac-address 00:11:11:01:01:12 vlan 2
description TP

TP-Link T1600G-52PS Specifications

General

PoE Ports	48
Switching Capacity	104 Gbps
Forwarding Rate	77.4Mpps
PoE Budget	384 W
Power Supply	AC 100-240V, 50/60Hz
Mounting	Rack Mountable
MAC Address Table	16K
Jumbo Frame	9KB
Packet Buffer Memory	4 MB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 90% non-condensing
Layer	Layer 2+
Dimensions (W x D x H)	440 x 44 x 44 mm
Standards and Protocols	IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at
Quality of Service	8 queues per port
VLAN	4K VLANs
Management	Web-based, SNMP
Security	802.1X
Ports	48 x 10/100/1000 Mbps RJ45 ports, 4 x 1G SFP slots
