TP-Link T1600G-52PS Cli Reference Guide

32
Example
Create a Protocol-based VLAN template named “TP” whose Ethernet
protocol type is 0x2024:
T1600G-52TS(config)#protocol-vlan template name TP frame ether_2
ether-type 2024
5.2 protocol-vlan vlan
Description
The protocol-vlan vlan command is used to create a Protocol-based VLAN.
To delete a Protocol-based VLAN, please use no protocol-vlan command.
Syntax
protocol-vlan vlan vlan-id { template template-idx }
no protocol-vlan vlan group-idx
Parameter
vlan-vid —— Specify IEEE 802.1Q VLAN ID, ranging from 1-4094.
template-idx ——The number of the Protocol-based VLAN Template. You can
get the template corresponding to the number by the
show protocol-vlan
template command.
group-idx ——The number of the Protocol-based VLAN entry. You can get
the Protocol-based VLAN entry corresponding to the number by the
show
protocol-vlan vlan command.
Command Mode
Global Configuration Mode
Privilege Requirement
Only Admin, Operator and Power User level users have access to these
commands.
Example
Create Protocol-based VLAN 2 and bind it with Protocol-based VLAN
Template 3:
T1600G-52TS(config)# protocol-vlan vlan 2 template 3

TP-Link T1600G-52PS Specifications

General

PoE Ports	48
Switching Capacity	104 Gbps
Forwarding Rate	77.4Mpps
PoE Budget	384 W
Power Supply	AC 100-240V, 50/60Hz
Mounting	Rack Mountable
MAC Address Table	16K
Jumbo Frame	9KB
Packet Buffer Memory	4 MB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 90% non-condensing
Layer	Layer 2+
Dimensions (W x D x H)	440 x 44 x 44 mm
Standards and Protocols	IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at
Quality of Service	8 queues per port
VLAN	4K VLANs
Management	Web-based, SNMP
Security	802.1X
Ports	48 x 10/100/1000 Mbps RJ45 ports, 4 x 1G SFP slots
