Phaser 6280 Color Laser Printer Service Manual 2-67
Theory of Operation
Dispenser Assembly (C) (M) (Y) (K)
The Dispenser drives the Agitator and the Auger in the Print Cartridge as
shown in the following diagram. The operation is common among the
Dispensers C, M, Y, and K.
CRU Assembly
Process
s6280-109
Dispenser Assembly (C) (M) (Y) (K)
Dispenser Input Gear
Cleaning Paddle Gear
[Cleaning Paddle]
Agitator Gear 2
Agitator Gear 2
[Front Agitator]
[Rear Agitator]
Dispenser Idler Gear 1
Main Developer
Agitator Gear
Main Developer Agitator Gear
[Rear Main Agitator]
[Front Main Agitator]
Dispenser Idler Gear 1
Dispenser Gear
[Dispenser Auger]
[Name of Moving Parts]
Cartridge Assy (K), Cartridge Assy (C), Cartridge Assy (M), Cartridge Assy (Y)
To Next Page
