Phaser 6280 Color Laser Printer Service Manual 3-59
Error Messages and Codes
Check Cartridge (Yellow/Magenta/Cyan/Black)
The Print Cartridge (Yellow/Magenta/Cyan/Black) tape was not removed
when a new Print Cartridge is installed.
Applicable Chain Links
■ Chain Link 093-919: IOT Yellow Cartridge Tape Staying
■ Chain Link 093-920: IOT Magenta Cartridge Tape Staying
■ Chain Link 093-921: IOT Cyan Cartridge Tape Staying
■ Chain Link 093-922: IOT Black Cartridge Tape Staying
Initial Actions
■ Check the Print Cartridge life using CentreWare IS.
■ Cycle printer power.
■ If problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Dispenser Assy., PL5.1.12
■ Print Cartridge (Y/M/C/K),
PL5.1.18-21
■ MCU Board, PL9.1.20
■ Top LV Harness, PL10.1.16
■ “Map 3 - Image Processor Board and
Dispenser” on page 10-11
■ “Map 4 - LVPS and MCU Boards” on
page 10-12
■ “Developer” on page 10-33
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1. Check the Print Cartridge tape.
2.Has the tape been removed?
Go to step 2. Remove the
tape on the
Print Cartridge.
Go to step 2.
2 Does the error still occur? Go to step 3. Complete.
3 1. Replace the Print Cartridge
(page 8-10).
2.Does the error still occur?
Go to step 4. Complete.
