Xerox Phaser 6280 Service Manual

Phaser 6280 Color Laser Printer Service Manual 1-19
General Information
Image Specifications
Note
The printer has 4 mm margins on all sides.
Refer to “Print-Quality Troubleshooting” on page 5-1 for detailed
specifications.
Characteristic Specification
Maximum Print Area 210.9 mm (8.3 inches) x 351.6 mm (13.8 inches)
Guaranteed Print Area 207.9 mm (8.2 inches) x 347.6 mm (13.7 inches)
Skew 190 mm ± 1.2 mm
Perpendicularity 114.5 mm ± 0.8 mm
Parallelism
Horizontal 180 mm ± 1.2 mm
Vertical 234 mm ± 1.2 mm
Linearity
Horizontal 190 mm ± 0.5 mm
Vertical 234 mm ± 0.5 mm
Slant 269 mm ± 1.2 mm
Magnification Error
Horizontal Simplex 190 mm ± 0.5%
Horizontal Duplex 190 mm ± 0.8%
Vertical Simplex 234 mm ± 0.5%
Vertical Duplex 234 mm ± 0.8%
Registration
Leading Edge 10.0 mm ± 2.0 mm
Side Edge 8.5 mm ± 2.5 mm

Xerox Phaser 6280 Specifications

General

Print Resolution	Up to 600 x 600 x 4 dpi
Processor	400 MHz
Operating System Compatibility	Windows, Mac OS, Linux
Print Technology	Laser
Monthly Duty Cycle	70, 000 pages
Memory	256 MB (standard)
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	A4, A5, B5, Executive, Legal, Letter
Maximum Paper Size	8.5 x 14 inches
