3-124 Phaser 6280 Color Laser Printer Service Manual
Error Messages and Codes
Tray 2 (PH) Motor Error
The Tray 2 Motor has failed.
Applicable Chain Link
■ Chain Link 042-325-03: IOT Motor Failure
Initial Actions
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Feeder Assembly, PL3.2.1
■ PH Drive Assembly, PL8.1.7
■ MCU Board, PL9.1.20
■ Right Side Harness, PL10.1.15
■ “Map 1 - Electrical and Drive” on
page 10-9
■ “Map 4 - LVPS and MCU Boards” on
page 10-12
■ “Tray 1 (MPT) and Registration” on
page 10-23
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1. Check the detailed error code (press
the Up and Down buttons
simultaneously).
2.Does code “03” display on the
Control Panel?
Go to step 2. ■ Refer to
“Main Motor
Error” on
page 3-120
■ Refer to “Sub
Motor Error” on
page 3-122
■ Refer to
“Optional
Feeder Motor
Error” on
page 3-126
2 1. Check the Rubber Registration
Roller for rotation.
2.Does the Roller rotate smoothly?
Go to step 3. Replace the
Feeder
Assembly
(
page 8-36).
3 1. Check the wiring harness
connectors P/J25 and P/J251
between the MCU Board and the PH
Drive Assembly.
2.Are the connectors securely
connected?
Go to step 4. Reconnect the
connectors.
Go to step 4.
To Next Page
