Phaser 6280 Color Laser Printer Service Manual 1-21
General Information
Mounting Surface Specifications
These specifications apply to any printer used as a table-top printer.
1. In order to function properly, the printer must be placed on a surface with
the following minimum dimensions.
2. Mounting surface flatness must be within the specified range.
600 mm
600 mm
1237 mm
100 mm
100 mm
130 mm
s6280-042
Right Hand Side
s6280-043
5mm Max
