Xerox Phaser 6280 Service Manual

Phaser 6280 Color Laser Printer Service Manual 5-9
Print-Quality Troubleshooting
Test Prints
This section provides information for how to analyze test prints. A variety of
test prints are available for determining the quality of output from the printer
and to assist in troubleshooting the problems.
■ No Image IOT
■ Pattern IOT
■ Grid 2 ESS
■ Cyan 20% ESS
■ Magenta 20% ESS
■ Yel low 2 0 % E SS
■ Black 20% ESS
■ CMY 20% ESS
■ Gradation ESS
■ Toner Pallet Check
■ Contamination Check
No Image IOT
This test print provides a sample of blank page. This test is used to identify
problems with the printer function.
■ Fail: Check the printer function.
■ Pass: Check the network connection, cable, PC...etc.
Blank Print

Xerox Phaser 6280 Specifications

General

Print Resolution	Up to 600 x 600 x 4 dpi
Processor	400 MHz
Operating System Compatibility	Windows, Mac OS, Linux
Print Technology	Laser
Monthly Duty Cycle	70, 000 pages
Memory	256 MB (standard)
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	A4, A5, B5, Executive, Legal, Letter
Maximum Paper Size	8.5 x 14 inches
