Phaser 6280 Color Laser Printer Service Manual 2-37
Theory of Operation
Electrical
Control Panel
The Control Panel displays the printer status and operates the printer.
s6280-083
Humidity/Temperature
Sensor
Interlock Switch
Power Switch
EEPROM Board
Image Processor Board
MCU Board
Interlock Switch
Humidity/Temperature
Sensor
Control Panel
Main Fan
LVPS
HVPS
Ready
C M Y K
s6280-084
