3-122 Phaser 6280 Color Laser Printer Service Manual
Error Messages and Codes
Sub Motor Error
The Sub Motor has failed.
Applicable Chain Link
■ Chain Link 042-325-01: IOT Motor Failure
Initial Actions
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ MCU Board, PL9.1.20
■ Right Side Harness, PL10.1.15
■ Main Drive, PL8.1.2
■ “Map 1 - Electrical and Drive” on
page 10-9
■ “Map 4 - LVPS and MCU Boards” on
page 10-12
■ “Main Drive” on page 10-25
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1. Check the detailed error code (press
the Up and Down buttons
simultaneously).
2.Does code “01” display on the
Control Panel?
Go to step 2. ■ Refer to
“Main Motor
Error” on
page 3-120
■ Refer to “Tray
2 (PH) Motor
Error” on
page 3-124
■ Refer to
“Optional
Feeder Motor
Error” on
page 3-126
2 1. Check the Print Cartridges for
correct installation.
2.Are the Print Cartridges correctly
installed?
Go to step 4. Reseat the Print
Cartridges
(
page 8-10).
Go to step 3.
3 Does the error still occur? Go to step 4. Complete.
4 1. Check the wiring harness
connectors P/J22 and P/J221
between the MCU Board and the
Main Drive Assembly.
2.Are the connectors securely
connected?
Go to step 5. Reconnect the
connectors.
Go to step 5.
To Next Page
