3-120 Phaser 6280 Color Laser Printer Service Manual
Error Messages and Codes
Main Motor Error
The Main Motor has failed.
Applicable Chain Link
■ Chain Link 042-325-01: IOT Motor Failure
Initial Actions
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Main Drive Assembly, PL8.1.2
■ MCU Board, PL9.1.20
■ Right Side Harness, PL10.1.15
■ “Map 1 - Electrical and Drive” on
page 10-9
■ “Map 4 - LVPS and MCU Boards” on
page 10-12
■ “Main Drive” on page 10-25
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1. Check the detailed error code (press
the Up and Down buttons
simultaneously).
2.Does code “00” display on the
Control Panel?
Go to step 2. ■ Refer to “Sub
Motor Error” on
page 3-122
■ Refer to “Tray
2 (PH) Motor
Error” on
page 3-124
■ Refer to
“Optional
Feeder Motor
Error” on
page 3-126
2 1. Check the Transfer Unit, Fuser, and
Black Print Cartridge for correct
installation.
2.Are the parts seated correctly?
Go to step 3. Reseat the
following items:
■ Transfer Unit
(page 8-8)
■ Fuser
Assembly
(page 8-11)
■ Black Print
Cartridge
(page 8-10)
■ Go to step 2.
3
Does the error still occur? Go to step 4. Complete.
