Xerox Phaser 6280 Service Manual

10-12 Phaser 6280 Color Laser Printer Service Manual
Plug/Jack and Wiring Diagrams
Map 4 - LVPS and MCU Boards
A
132
133
134
135
136
137
138
139
140
141
142
143
144
145
131
BCDEFGHI JKL
s6280-272
261
*(CN1)
44
502
501
144
482
48
47
504
503
40
483
* The CN1 is printed on the board.
17 16 12
28 30 29
14
10
13
19
15
18
101
26
20
31
22
24
25
23
27

Xerox Phaser 6280 Specifications

General

Print Resolution	Up to 600 x 600 x 4 dpi
Processor	400 MHz
Operating System Compatibility	Windows, Mac OS, Linux
Print Technology	Laser
Monthly Duty Cycle	70, 000 pages
Memory	256 MB (standard)
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	A4, A5, B5, Executive, Legal, Letter
Maximum Paper Size	8.5 x 14 inches
