Xerox Phaser 6280 Service Manual

3-150 Phaser 6280 Color Laser Printer Service Manual
Error Messages and Codes
MACPHY Internal Loop Test Error
MACPHY Internal Loop Test error occurs.
Applicable Chain Link
■ Chain Link 116-393: MACPHY Int Loop Test Error (Diag Mode)
Initial Actions
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Image Processor Board, PL9.1.27
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1.Reboot the printer.
2.Does the error still occur?
Go to step 2. Complete.
2 1. Reseat the Image Processor Board
(page 8-87).
2.Does the error still occur?
Replace the
Processor Board
(
page 8-87).
Complete.

Xerox Phaser 6280 Specifications

General

Print Resolution	Up to 600 x 600 x 4 dpi
Processor	400 MHz
Operating System Compatibility	Windows, Mac OS, Linux
Print Technology	Laser
Monthly Duty Cycle	70, 000 pages
Memory	256 MB (standard)
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	A4, A5, B5, Executive, Legal, Letter
Maximum Paper Size	8.5 x 14 inches
