Xerox Phaser 6280 Service Manual

Phaser 6280 Color Laser Printer Service Manual 3-119
Error Messages and Codes
Over Heat
The Temperature Sensor has detected high temperature.
Applicable Chain Link
■ Chain Link 042-700: IOT Over Heat Stop
■ Chain Link 142-700: IOT Over Heat Forced Half Speed
Initial Actions
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Feeder Assembly, PL3.2.1
■ MCU Board, PL9.1.20
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1. Check the room temperature.
2.Is the room temperature over
32° C?
Change the
room
temperature or
move the printer
to a different
location.
Go to step 2.
2 1. Check the print usage.
2.Did the user print a large volume of
document?
Go to step 3. Go to step 4.
3 1. Allow the printer to cool down for
about five minutes.
2.Does the error still occur?
Go to step 4. Complete.
4 1. Check the MCU Board for correct
installation. Reseat the MCU Board
(page 8-86).
2.Does the error still occur?
Go to step 5. Complete.
5 1. Replace the MCU Board
(page 8-86).
2.Does the error still occur?
Replace the
Feeder
Assembly
(
page 8-36).
Complete.
