Phaser 6280 Color Laser Printer Service Manual 9-47
Parts List
Service Kits
Service Kits are developed to provide an easy means to obtain spare parts
normally associated with larger assemblies. A number of Service Kits have
been developed for the Phaser 6280. The following tables list the contents for
each kit.
Kits
Pin Kit
Parts List
Reference
Description Part Number
1.2.98 Pin Kit (with 1.2.8, 1.2.17, 1.2.30) 675K74260
PL1.2.8 Shaft Pivot
PL1.2.17 Pin Pivot MPT
PL1.2.30 Shaft Pivot MPT
Hardware Kit
Parts List
Reference
Description Part Number
99.99.90 Hardware Kit 604K34030
Screw, Bind Head Del (1)
Screw, 8 mm Plastic (1)
Screw, Tap Bind Head (1)
Screw, M3x6 B (1)
Screw, DT3x8 B (1)
E-Ring, 3 mm (1)
E-Ring, 4 mm (1)
Packaging Kit
Parts List
Reference
Description Part Number
Re-Packaging Kit 604K55460
