Xerox Phaser 6280 Service Manual

9-48 Phaser 6280 Color Laser Printer Service Manual
Parts List
Harness Kits
Parts List
Reference
Description Part Number
99.99.91 Kit Harness Front Cover STD 675K74250
962K39540
604K38541
604K38541
PL1.2.11 Harness Assy Front Cover
(J272-P2720, P2721, T4322-T43221)
PL1.2.15 Harness Assy Z-X Operation Panel
(J220-P2900)
PL1.2.32 Harness Assy ESS (J29-J2900)
99.99.92 Kit Harness Feeder/Fuser/Interlock STD 675K74380
PL3.1.17 Harness Assy MPT NPP (J282-J2821) 962K41560
PL3.2.37 Harness Assy Regi Sensor (J292-J2921, J2922) 962K38300
PL6.1.11 Harness Assy Fuser (P171-J17, J47),
100V/115V
962K39660
PL6.1.11 Harness Assy Fuser (P171-J17, J47) - 200V 962K39790
PL9.1.3 Harness Assy Interlock (Interlock Switch-J44) 962K39700
99.99.93 Kit Harness Power Switch STD 675K74370
962K44990
962K45030
962K39480
962K39740
962K39510
PL9.1.16 Harness Assy AC IN 110V
(Switch Power - J48, J482, FS483,-T484)
PL9.1.16 Harness Assy AC IN 240V
(Switch Power - J48, J481)
PL10.1.4 Harness Assy Humidity (J26-J261)
PL10.1.9 Harness Assy CRU SNR
(J19-J191, J192, J193, J194)
PL10.1.13 Harness Assy CRUM
(J31, J311, J312, J313, J314)
PL10.1.15 Harness Assy Right Side (J22, J23, J24, J25,
J27, J28, J29, J30-J144, J221, J222, P231,
P232, P233, P234, P235, P241, J251, P272,
J281, P282, J291, P292, P301)
PL10.1.16 Harness Assy LV Top
(J13, J14, J15, J18, J401, J5041-J141, P181,
P182, P183, P184, J40, J501, J502, J504)
PL10.1.18 Harness Assy IF (J10-J101, J111)
