Xerox Phaser 6280 Service Manual

Phaser 6280 Color Laser Printer Service Manual 3-123
Error Messages and Codes
5 1. Perform the Sub Motor test
(page 4-42): Service Mode >
Engine Diag > Motor Test > Sub
Motor. During the test, close the
Front Cover.
2.Does the Motor operate properly?
Replace the
MCU Board
(
page 8-86).
Go to step 6.
6 1. Check the Main Drive Assembly for
correct installation.
2.Is the Main Drive Assembly
correctly installed?
Go to step 7. Reseat the Main
Drive Assembly
(
page 8-70).
Go to step 8.
7 Does the error still occur? Go to step 8. Complete.
8 Check the Right Side Harness for
continuity.
1.Disconnect P/J22 from the MCU
Board and P/J221 from the Main
Drive Assembly.
2.Check continuity between P/J22 <=>
P/J221.
Go to step 9. Replace the
Right Side
Harness.
9 Check the Main Drive Assembly signal.
1.Disconnect P/J22 from the MCU
Board.
2.Are there +24 V across ground <=>
J22-A2/J22-A4 pin when the
Interlock Switch is activated?
Replace the
Main Drive
Assembly
(
page 8-70).
Replace the
MCU Board
(
page 8-86).
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6280 Specifications

General

Print Resolution	Up to 600 x 600 x 4 dpi
Processor	400 MHz
Operating System Compatibility	Windows, Mac OS, Linux
Print Technology	Laser
Monthly Duty Cycle	70, 000 pages
Memory	256 MB (standard)
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	A4, A5, B5, Executive, Legal, Letter
Maximum Paper Size	8.5 x 14 inches
