Xerox Phaser 6280 Service Manual

2-72 Phaser 6280 Color Laser Printer Service Manual
Theory of Operation
Front View
Duplex Mode
s6280-114
[ Name Of Moving Parts ]
Fuser
Exit Idle Gear 6
Exit Idle Gear 6
Exit Gear
Paper
Main Drive Assembly
[ Exit Roller
Assembly ]
Exit Clutch Assembly
Exit Idle Gear 6
Exit Idle Gear 4
Exit Idle Gear 3
Exit Idle Gear 2
Duplex Idle Gear 1
Duplex Idle Gear 2
Duplex Gear 25z
Duplex Gear 21z 25z
Duplex Idle
Gear 21z
Duplex Clutch
Duplex Module
Duplex Motor
Duplex Gear 40z
[ Duplex Roller
Assembly 1 ]
[ Duplex Belt ]
[ Duplex Roller
Assembly 2 ]
Front

Xerox Phaser 6280 Specifications

General

Print Resolution	Up to 600 x 600 x 4 dpi
Processor	400 MHz
Operating System Compatibility	Windows, Mac OS, Linux
Print Technology	Laser
Monthly Duty Cycle	70, 000 pages
Memory	256 MB (standard)
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	A4, A5, B5, Executive, Legal, Letter
Maximum Paper Size	8.5 x 14 inches
