Phaser 6280 Color Laser Printer Service Manual 3-9
Error Messages and Codes
042-325-00 Main Motor Error page 3-120
042-325-01 Sub Motor Error page 3-122
042-325-03 Tray 2 (PH) Motor Error (Print Engine Motor
Failure)
page 3-124
042-325-04 Optional 550 Motor Error
(Print Engine Motor Failure)
page 3-126
042-358-01 Fan Motor Error (Rear) page 3-111
042-358-02 Fan Motor Error (Duplexer) page 3-114
042-372 Deve Mode Error page 3-117
042-700 Over Heat page 3-119
061-370 Laser Error page 3-129
072-215 550 Feeder Error (Option Feeder Failure) page 3-130
077-215 Duplexer Error
(IOT Option Duplexer Failure)
page 3-132
077-300 Door A Open (Print Engine Front Cover Open) page 3-134
092-651 ADC Sensor Error (High Density) page 3-135
092-651 ADC Sensor Error (Low Density) page 3-139
092-661 Environmental Sensor Error page 3-143
116-314 Controller System Error (On Board Network
MAC Address Checksum Error)
page 3-145
116-315 Controller System Error
(ESS On Board RAM W/R Check Fail)
page 3-145
116-316 RAM Error (ESS DIM Slot RAM W/R Check Fail) page 3-147
116-317 Controller System Error
(Controller Error (ROM Check Fail) (Main))
page 3-145
116-320 RAM Error (DIMM Slot RAM Error) page 3-147
116-323 Controller System Error
(NVRAM Error (NVRAM1 W/R Check Fail))
page 3-145
116-324 Controller System Error (Illegal Exception) page 3-145
116-326 Controller System Error
(NVRAM2 W/R Check Fail)
page 3-145
116-327 Controller System Error
(Instruction Cache Error)
page 3-145
116-328 Controller System Error (Data Cache Error) page 3-145
116-333 Hard Disk Error (PCI Option #0 Fail) page 3-151
116-343 Controller System Error (ASIC Error (ASIC Fail)) page 3-145
116-350 Network Error
(On Board Network Communication Fail)
page 3-104
Error Message and Chain Link Code Display (continued)
Chain Link
Code
Control Panel Message Go to Page
