Xerox Phaser 6280 Service Manual

3-56 Phaser 6280 Color Laser Printer Service Manual
Error Messages and Codes
5 Check the Top LV Harness for continuity.
1.Disconnect P/J 47 and P/J501 from the
LVPS.
2.Disconnect P/J13 from the MCU Board.
3.Check continuity between:
■ P/J47 <=> P/J171
■ P/J501 <=> P/J13
Go to step 6. Replace the
Top LV
Harness.
6 1. Replace the Fuser (page 8-11).
2.Does the error still occur?
Go to step 7. Complete.
7 1. Replace the LVPS (page 8-80).
2.Does the error still occur?
Replace the
MCU Board
(
page 8-86).
Complete.
Troubleshooting Procedure
Step Actions and Questions Yes No

Xerox Phaser 6280 Specifications

General

Print Resolution	Up to 600 x 600 x 4 dpi
Processor	400 MHz
Operating System Compatibility	Windows, Mac OS, Linux
Print Technology	Laser
Monthly Duty Cycle	70, 000 pages
Memory	256 MB (standard)
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	A4, A5, B5, Executive, Legal, Letter
Maximum Paper Size	8.5 x 14 inches
