Xerox Phaser 6280 Service Manual

Phaser 6280 Color Laser Printer Service Manual 3-71
Error Messages and Codes
5 Check the Front Cover Harness for
continuity.
1.Disconnect P/J272 from the Right Side
Harness and P/J2721 from the Transfer
Unit.
2.Check continuity between P/J272 <=> P/
J2721.
Go to step 6. Replace the
Front Cover
Harness.
6 1. Replace the Transfer Unit (page 8-8).
2.Does the error still occur?
Replace the
MCU Board
(
page 8-86).
Complete.
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6280 Specifications

General

Print Resolution	Up to 600 x 600 x 4 dpi
Processor	400 MHz
Operating System Compatibility	Windows, Mac OS, Linux
Print Technology	Laser
Monthly Duty Cycle	70, 000 pages
Memory	256 MB (standard)
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	A4, A5, B5, Executive, Legal, Letter
Maximum Paper Size	8.5 x 14 inches
