3-128 Phaser 6280 Color Laser Printer Service Manual
Error Messages and Codes
13 Check the Right Side Harness for
continuity.
1.Disconnect P/J281 from the Feeder
Harness and P/J28 from the MCU
Board.
2.Check continuity between P/J281
<=> P/J28.
Go to step 14. Replace the
Right Side
Harness.
14 Check the Tray 3 Feeder Board signal.
1.Disconnect P/J28 from the MCU
Board.
2.Are there +24 V across ground <=>
J28-4/J28-5 pin when the Interlock
Switch is activated?
Replace the
Optional 550-
Sheet Feeder
(
page 8-100).
Replace the
MCU Board
(
page 8-86).
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6280 Specifications

General

Print Resolution	Up to 600 x 600 x 4 dpi
Processor	400 MHz
Operating System Compatibility	Windows, Mac OS, Linux
Print Technology	Laser
Monthly Duty Cycle	70, 000 pages
Memory	256 MB (standard)
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	A4, A5, B5, Executive, Legal, Letter
Maximum Paper Size	8.5 x 14 inches
