Xerox Phaser 6280 Service Manual

3-142 Phaser 6280 Color Laser Printer Service Manual
Error Messages and Codes
20 Check the Right Side Harness for
continuity.
1.Disconnect P/J27 from the MCU
Board and P/J272 from the Front
Cover Harness.
2.Check continuity between P/J27 <=>
P/J272.
Go to step 21. Replace the
Right Side
Harness.
21 Check the ADC Sensor signal.
1.Disconnect P/J27 from the MCU
Board.
2.Is there +5 V across ground <=>
J27-7 pin?
Replace the
Transfer Unit
(
page 8-8).
Replace the
MCU Board
(
page 8-86).
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6280 Specifications

General

Print Resolution	Up to 600 x 600 x 4 dpi
Processor	400 MHz
Operating System Compatibility	Windows, Mac OS, Linux
Print Technology	Laser
Monthly Duty Cycle	70, 000 pages
Memory	256 MB (standard)
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	A4, A5, B5, Executive, Legal, Letter
Maximum Paper Size	8.5 x 14 inches
